Globe Spherical Bollard
Materials:
Steel, construction material S 235 JR, hot-dip galvanized according to DIN EN ISO 1461 and powder coated in three assembly levels through sweep–blasting, priming and application of a top coat colour RAL 9010 pure white with 3 pieces red photoluminescent strips o r DB… iron mica fine structure matt o r RAL …. smooth silk-gloss according to DIN 55633 after category C5 (heavy anti corrosive coating).
Available measurements in mm:
| Model | Diameter |
Height ab. Gound |
| stationary, for embedding | 82 | 900 |
| stationary, for dowelling with base plate | 82 | 900 |
| removable, with triangular key operated lock, for embedding | 82 | 900 |
| removable, with cylinder lock, for embedding | 82 | 900 |
| fold-away, with triangular key operated lock, for embedding | 82 | 900 |
| fold-away, with triangular key operated lock, for dowelling | 82 | 900 |
| fold-away, with cylinder lock, for embedding | 82 | 900 |
| fold-away, with cylinder lock, for dowelling | 82 | 900 |
Options / Accessory:
| - colour coating, RAL or DB-card | |
| - triangular key | |
| - 3 pcs. photoluminescent strips | |
|
- chain-eye, steel, 1-sided |
|
| - chain-eye, steel, 2-sided | |
|
- chain, steel |
|
|
- steel s-hook |
|
|
- steel link |
|
|
- snap hook |
|
| - steel clevis | |
| - ground socket, steel, galv. for 70 x 70 bollards | |
|
- cover for ground socket, spring loaded locking mechanism, for 70 x 70 mm bollards |
|
|
- ground rosette fpr diameter 76 mm an 89 mm |
Mounting Options:
- for embedding
- for dowelling
